Baileigh 1004816 HSP-30A 30 Ton Pneumatic/Hand Operated H-Frame Press

Features

• 21.653” working width.
• 5.9” cylinder stroke.
• Industrial-grade hydraulic parts ensure smooth, dependable use for years.
• Cylinder can move left and right within the frame, depending on orientation of the job.
• You have the option to work the HSP-30A manually, if you need finer control.
• Comes standard with a set of V-blocks.
• Rigid, fully-welded steel main frame eliminates flexing at full force to deliver accurate results.
• Typically in stock for fast deliveries.

What’s in The Box

• HSP-30A – Air/Hand Operated H-Frame Shop Press
• Owner’s Manual

Warranty

• 1 Year Limited Factory Warranty
• 30 Day Satisfaction Guaranteed

Specifications

SKU	HSP-30A
Power	Pneumatic / Manual
Piston Head Diameter	2.375″
Movable Cylinder	Yes
Working Width	21.653″
Maximum Capacity	30 tons
Cylinder Stroke	5.9″
Cylinder Diameter	4.5″
Distance From Table To Ram	Min. 5.94″ – Max. 40.59″
Dimensions (Inches)	75 x 31 x 11
Weight	430 lbs
