Features
- 4’ x 8’ table to fit common bulk industrial material sizes.
- Perfect for solid wood processing, making closet doors, furniture, signs, and much more.
- 0 to 18,000 rpm variable spindle speed range.
- 7.4 hp spindle has the power to cut hardwoods quickly and precisely.
- Spindle is air-cooled to prevent overheating, prolong the machine’s lifespan, keep it producing high-quality cuts.
- 15,000 mm per minute maximum engraving or travel speed.
- Solid steel gantry can tackle hardwoods at high speeds without flinching.
- Stepper motors with square rails ensure smooth movement along the X, Y, and Z axes.
- Use the handheld digital controller to move the spindle, adjust the speed, and go through your design.
- Comes standard with software that allows you to set up almost any kind of design. (Details below.)
- Upload your cut pattern to the table with a USB drive.
- Rack and pinion mechanism holds up over long periods of heavy use and allows for more fluid and precise movement than a ball and screw mechanism
- 4 collets accept any standard tooling profiles with ?”, ¼”, 3/8″, and ½” bit sizes.
- Includes 10 different tooling profiles.
- Steel T-clamps hold the material down on the table to reduce vibrations and prevent errors.
- Table is preplummed 4 vacuum zones, each with a separate valve and handle, ready to accept optional 7hp vacuum pump. (Found Here)
- Extremely rigid steel structure reduces vibrations and helps the table stay accurate for years.
- Dust shroud covers the spindle and vacuums out sawdust and wood chips while you’re cutting.
- This combination CNC Router Table 4×8 is covered by a 1-year parts warranty.
.
What’s in The Box
- WR-84V – CNC Routing Table
- Owner’s Manual
Warranty
- 1 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | WR-84V |
| Power | 220V Single Phase |
| Actual Working Area | 97″ x 48″ |
| Spindle | 7.4hp |
| Z Axis Stroke | 5.375″ |
| Maximum Moving Speed (Inches Per Minute) | 590 |
| Maximum Engraving Speed (Inches Per Minute) | 590 |
| Reposition Accuracy | 0.0019 |
| Tool Diameters | ER32 |
| Length | 118″ |
| Width | 78″ |
| Height | 65″ |
| Weight (lbs) | 2500 |
| Table Style | T-Slot with Vacuum Option |
| Notes | Table comes ready to accept an optional vacuum pump. Pump must be purchased separately. |
| AMP Draw | 35 at full load |
| Dimensions (Inches) | 124 x 86 x 70 |
| Weight | 3000 lbs |
