Features
- 11 interchangeable Attachments available to tailor the Ironworker to your needs
- 17 optional Accessories available to increase precision and efficiency
- PowerLink System increases your capabilities by turning your Ironworker into a power source for our ever-expanding line of Hydraulic Tools
- Compact machine that allows for fast and easy transitions between fabrication operations: punch, shear, notch, bend and cope all in one machine
- Optimized workstation heights for improved efficiency
- Electric foot pedal with integrated jog control
- Adjustable electric stoke control
- Bright LED lights increase visibility
- ANSI B11.5-1988(02) Compliant Guarding
What’s in The Box
- 4 – Stations
- Shear
- Punching station
- Angle shear
- Open station for optional tooling
- Owner’s Manual
Warranty
- 1 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | 55231522 |
| Brand | Edwards |
| Volts | 208V/230V |
| Horsepower | 5 |
| Valve Pressure | 2500 PSI |
| Stations | 4 |
| Rated Capacity | 55 tons |
| Punching Capacity | 1-1/16 in diameter in 5/8 plate |
| Punching Throat Depth | 7-1/2 in |
| Punching Work Height | 36-9/16 in |
| Flat Bar Shearing Max Capacity | 3/8 x 14 x – 1/2 x 12 – 3/4 x 4 in |
| Flat Bar Shearing Max Round | 7/8 in |
| Flat Bar Shearing Max Square | 7/8 in |
| Flat Bar Shearing Work Height | 34-1/2 in |
| Angle Shear Max Capacity | 3 x 3 x 3/8 – 4 x 4 x 1/4 in |
| Angle Shear Work height | 39-7/8 in |
| Throat Depth | 11-3/16 in |
| Stroke | 1-1/4 in |
| Dimensions (L x W x H) | 36-1/8 x 44-3/8 x 55-1/4 in |
| Weight | 2480 lbs |
