Generac 7000 240 Volt Standby Generator Smart Management Module

Features

• These modules are essential to a Generac power management system.
• They work with your transfer switch, monitoring each selected circuit and automatically supplying power where it’s needed so you can get the most from your generator.
• A Generac power management system can use up to eight individual Smart Management Modules, depending on your needs. Just as important, you can set the load priority for each – putting you in control of which circuits matter most.

What’s in The Box

• Standby Generator Smart Management Module
• Owner’s Manual

Warranty

• 1-Year Limited Factory Warranty
• 30 Day Satisfaction Guaranteed

Specifications

Sku	7000
Brand	Generac
Voltage	230V AC
Contact Voltage	220V/240V AC
Contactor Coil Voltage	240V AC
Coil Inrush	30V
Coil Sealed	6.5V
Poles	2
Resistive Amperage	50A
F/L Inductive Amperage	40A
Locked Rotor Amperage	180A
NEMA Enclosure	3R
Enclosure Rating	UL 50
Frequency Selectability	50 Hz / 60 Hz
Depth	3.7 in.
Width	7.06 in.
Height	6.17 in.
Product Weight	2.06 lbs.
