Features
- Test lead holder on side of the clamp and optional magnetic hanger for the meter (Cat. Nos. 69445 or 69417) for hands-free operation
- Non-contact voltage tester integrated into the clamp jaw
- High-visibility reverse contrast LCD for improved viewability in all ambient lighting conditions
- Automatically ranging True Root Mean Squared (TRMS) measurement technology for accuracy
- Measures AC/DC and NCVT via a clamp and AC/DC voltage, resistance, frequency, DC microamps, capacitance, duty cycle, diode test, and continuity via test-leads, and temperature with a thermocouple
- Measures temperature with a K-Type thermocouple probe
- Max/Min, Rel/Zero and Data Hold capability
- Auto-power off after 10 minutes to conserve battery life
- Includes a carrying case, test leads with CAT III/CAT IV safety caps, thermocouple, instructions, and 3 x AAA batteries
- Low battery indicator and easily accessible battery compartment
- Built to withstand a 6.6-foot (2 m) drop
- CAT III 600V, Class 2, Double insulation safety rating
- Meets requirements for use in basic and controlled electromagnetic environments like residential, office, and light-industrial locations
What’s in The Box
- Clamp Meter
- Carrying Case
- Test Leads
- Thermocouple
- (3 x AAA) Batteries
- Owner’s Manual
Warranty
- Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | CL390 |
| Brand | Klein |
| Voltage | 600 V AC/DC |
| Frequency | 10 hz to 60 hkhz for 8 V to 220V AC |
| Type | AC/DC Current TRMS Clamp |
| Display | 4000 Count Reverse Contrast |
| Jaw Size | 1.6 in |
| Drop Protection | 6.6 in |
| Current | 400 A AC/DC |
| AC Voltage | 600V |
| DC Voltage | 600V |
| DC Polarity Indicator | Yes |
| Length | 8.4 in |
| Width | 3.5 in |
| Height | 1.5 in |
| Weight | 11 oz |
