Features
- 14″ Resaw capacity for cutting large pieces of wood, slicing veneers and cutting book matched panels
- 21-1/2″ x 16″ precision ground cast iron table for added stability and work support
- Fence system features a micro-adjustable, dual-position side plate
- Tool-less, independently adjustable, upper and lower ball bearing guides
- Rigid, four-sided guide post with rack and pinion adjustment for optimum blade support
- Easy-to-read blade tension scale can be viewed through upper door window
- Single knob adjustment simplifies the blade tracking process
- Blade tracking window provides clear view of blade during tracking
- Heavy duty tensioning with quick release features three settings: full tension, partial tension and full release
- Cast iron trunnion for maximum support and stability
- Slotted table allows for front blade removal
- Cast iron handwheels and ergonomically designed knobs make adjustments smooth and easy
- Round table insert features leveling screws for precise adjustment
- Conveniently located dual 4″ dust collection ports catch dust and chips at the source
- Table tilts 5-Degrees left and 45-Degrees right to accommodate a wide variety of cuts
What’s in The Box
- 230-Volt 15-Inch 3-Hp Stationary Vertical Bandsaw
- Owner’s Manual
Warranty
- 5-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Sku | 714650 |
| Brand | Jet |
| Voltage | 230v |
| Amperage | 12A |
| Horsepower | 3 Hp |
| Phase | 1-Phase |
| Recommended Circuit Size | 30 Amps |
| Band Saw Size | 14-3/4 in. |
| Cutting Capacity Width | 14-1/8 in. |
| Cutting Capacity Height | 14 in. |
| Blade Length | 133 in. |
| Blade Speed | 3,100 SFPM |
| Blade Width | 1/2 in. 6-Tpi |
| Max. Saw Blade Width | 1 in. |
| Min. Saw Blade Width | 1/8 in. |
| Table Tilt | -5.45 Degrees |
| Table Height From Floor | 35 in. |
| Dust Port Outside Diameter | (2) 4 in. |
| Table Size (L x W x H) | 21-1/5 in. x 16 in. x 2 in. |
| Shipping Weight | 450 lbs. |
