Tools & Equipment Makita HR4013C 1-9/16-Inch 11.0 Amp 8.4-Ft. Lbs Corded AVT Rotary Hammer

Features

• Powerful 11 AMP motor delivers 8.4 ft.lbs. of impact energy to handle the most demanding applications
• Anti-Vibration Technology (AVTa‚a) is a synchronized, three-component system that more effectively reduces vibration resulting in a low 5m/s2
• Air actuated counterbalance directs air pressure from the crank and barrel room into the counterbalance cylinders to move counterweight pistons in the opposite direction of the drive piston actively reducing vibration
• Vibration absorbing housing features a spring loaded main handle and upper housing that move independently of the motor and drive mechanism effectively isolating most of the vibration away from the user
• Integrated damper spring at the base of the impact bolt is engineered to absorb impact vibrations from the drill bit
• Lock-on or trigger activation in Chipping Only mode with a push button start/stop control for more convenient operation
• Constant speed control automatically applies additional power to the motor to maintain speed under load to complete the most challenging jobs
• Soft start suppresses start-up reaction for more control and better accuracy
• Ergonomic rubberized grip provides added comfort
• L.E.D. service light notifies the user approximately 8 hours before the brushes need to be replaced
• L.E.D. power light indicates switch failure or cord damage
• 2-mode operation for Chipping Only or Hammering with Rotation
• 24 bit angle settings allow the bit to be set at different positions for operating convenience
• Variable speed control dial enables user to match the speed to the application for greater versatility
• One-touch sliding chuck for quick bit changes

What’s in The Box

• (1) Makita 1-9/16 AVTa‚a Rotary Hammer
• (1) Side Handle (196792-8)
• (1) Depth Rod (331955-1)
• (1) Side Grip Assembly (123138-5)
• (1) Bit Grease (194683-7)
• (1) Cloth F/Wiping Oil (443122-7)
• Owneraa‚a„s Manual

Warranty

• 1-Year Limited Factory Warranty
• 30 Day Satisfaction Guaranteed

Specifications

AMPS	11
Capacity (Concrete)	1-9/16
Impact Energy (Joules)	11.4 J
Blows Per Minute (Variable Speed)	1,450 – 2,900 BPM
Bit Type	Accepts SDS-MAX
Overall Length	18-11/16
Cord Length (Ft)	16.4′
Net Weight	15.1 Lbs.
Shipping Weight	22 Lbs
